Details
| Model | CN18 | CN23 |
| Drilling/tapping ability | 16mm/M6 | 20mm/M20 |
| The spindle taper | B16 | MT2 |
| Maximum spindle stroke | 100mm | 120mm |
| Spindle speed | CVT 100-2500rpm | CVT 100-2500rpm |
| Distance between spindle end and mesa | 650mm | 600mm |
| Spindle motor power | 130-2.0KW Servo motor | 130-2.6KW Servo motor |
| Z-axis feed motor power (servo) | 0.75KW | 1KW |
| The spindle diameter | 60mm | 70mm |
| Control system | PLC and touch screen | PLC and touch screen |
| Feed way | Ball screw | Ball screw |
| Weight | 250kg/175kg | 400kg/300kg |
| Volume | 880*610*1000mm | 1000*700*1400mm |
